tenpest - 10-line "Tempest"-ish game in TurboBASIC XL for the Atari 8-bit

A simple game that reminds you of the classic Atari arcade game Tempest, but fits in 10 lines of BASIC!

tenpest is an offensive-only game, which ends after a time limit runs out. Your goal is to get as high a score as you can, by blasting enemies when they're as far away as possible.

Atari XL or XE computer (or 800 with Incognito board, I guess?), capable of running TurboBASIC XL — or an emulator — and a joystick.

Use a joystick in port 1. Press left/right to move your blaster around the edge of the surface. Any enemies within the same segment as your blaster will be destroyed automatically.

The further down the tube an enemy is when your blaster shoots it, the more points you receive. If the enemy is at the very edge, no points are awarded.

As you receive points, they're displayed in the text window at the bottom of the screen.

Once time runs out, the game ends. Your final score will have already been visible on the screen. Type "RUN" and press [Return] to start a new game.

For each of the 10 lines of source code, the abbreviated version (which fits within 120 characters) is shown, immediately followed by an expanded version that's slightly more readable. Then, each individual command is shown, and its purpose is explained, using nested bullet lists (to show the code's structure within IF/ENDIF, FOR/NEXT, etc. blocks).

Set-up

10 POKE 559,0:DEG:DIM CX(12),CY(12),R(12),BA(5),BR(5),S$(3840):F.A=0TO11:CX(A)=COS(A*30):CY(A)=-SIN(A*30)
10 POKE 559,0:DEG:DIM CX(12),CY(12),R(12),BA(5),BR(5),S$(3840):FOR A=0 TO 11:CX(A)=COS(A*30):CY(A)=-SIN(A*30)

• POKE 559,0 — Disable ANTIC (graphics chip) DMA (direct memory access), which gives the CPU some extra time to do work. (Result: screen is blanked, and BASIC runs a little faster.)
• DEG — Switch trigonometric functions to use degrees (vs. radians).
• DIM CX(12),CY(12),R(12),BA(5),BR(5),S$(3840) — create storage for the trig. fast look-up table (CX, CY), and the radii of the web (it gets a fancy shape, vs. being a circle-like polygon) (R), as well as the enemy's location around the web (BA), and distance up the web (BR); finally also some storage for a copy of screen data (S$)
• FOR A=0 TO 11 — loop 12 times (number of segments of the web)
  • CX(A)=COS(A*30) — fill in cosine look-up table
  • CY(A)=-SIN(A*30) — fill in sine look-up table

20 R(A)=20+RAND(20):N.A:GR.7:COL.1:CX=79:CY=40:Z=ADR(S$):DPOKE708,36032:PL.CX(0)*R(0)+CX,CY(0)*R(0)+CY:SC=DPEEK(88)
20 R(A)=20+RAND(20):NEXT A:GRAPHCIS 7:COLOR 1:CX=79:CY=40:Z=ADR(S$):DPOKE 708,36032:PLOT CX(0)*R(0)+CX,CY(0)*R(0)+CY:SC=DPEEK(88)

• R(A)=20+RAND(20) — pick a random radius for an endpoint of each segment (to make it non-circular)
• NEXT A
• GRAPHCIS 7 — switch to 160x96 4-color bitmap mode (ANTIC DMA gets reenabled, BTW)
• COLOR 1 — set drawing color to 1
• CX=79:CY=40 — quick look-up for the center of the web (79,40)
• Z=ADR(S$) — quick look-up for the address of the storage at S$
• DPOKE 708,36032 — set what color colors 1 and 2 draw
• PLOT CX(0)*R(0)+CX,CY(0)*R(0)+CY — plot a point at the first segment's endpoint, up close
• SC=DPEEK(88) — quick look-up for the address of the start of screen memory

30 F.A=1TO11:DR.CX(A)*R(A)+CX,CY(A)*R(A)+CY:N.A:DR.CX(0)*R(0)+CX,CY(0)*R(0)+CY:PL.CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY
30 FOR A=1 TO 11:DRAWTO CX(A)*R(A)+CX,CY(A)*R(A)+CY:NEXT A:DRAWTO CX(0)*R(0)+CX,CY(0)*R(0)+CY:PLOT CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY

• FOR A=1 TO 11 — loop around the rest of the web (1 thru 11)
  • DRAWTO CX(A)*R(A)+CX,CY(A)*R(A)+CY — draw a line to the next segment
• NEXT A
• DRAWTO CX(0)*R(0)+CX,CY(0)*R(0)+CY — draw a line back to the first segment
• PLOT CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY — plot a point at the first segment's endpoint, far away

40 F.A=1TO11:DR.CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY:N.A:DR.CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY:POKE710,66:F.A=0TO11
40 FOR A=1 TO 11:DRAWTO CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY:NEXT A:DRAWTO CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY:POKE 710,66:FOR A=0 TO 11

• FOR A=1 TO 11 — loop around the rest of the web
  • DRAWTO CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY — same as before
• NEXT A
• DRAWTO CX(0)*R(0)/8+CX,CY(0)*R(0)/8+CY — same as before
• POKE 710,66 — set what color color 3 draws
• FOR A=0 TO 11 — loop around the entire web

50 PL.CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY:DR.CX(A)*R(A)+CX,CY(A)*R(A)+CY:N.A:A=0:F.I=0TO4:BA(I)=-1:N.I:MOVE SC,Z,3840
50 PLOT CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY:DRAWTO CX(A)*R(A)+CX,CY(A)*R(A)+CY:NEXT A:A=0:FOR I=0 TO 4:BA(I)=-1:NEXT I:MOVE SC,Z,3840

• PLOT CX(A)*R(A)/8+CX,CY(A)*R(A)/8+CY — plot a point at this segment's endpoint, far away
• DRAWTO CX(A)*R(A)+CX,CY(A)*R(A)+CY — drawto its endpoint, up close
• NEXT A
• A=0 — set the blaster's position around the web
• FOR I=0 TO 4 — loop through all enemies
  • BA(I)=-1 — disable them (set their segment to -1, which is invalid)
• NEXT I
• MOVE SC,Z,3840 — now that the empty web has been drawn, copy a chunk of screen memory into S$ to take a snapshot of it

Main loop

60 MOVE Z,SC,3840:S=STICK(0):IF S=11:A=(A+1)MOD12:ELSE:IF S=7:A=A-1:IF A<0:A=11:END.:END.:END.:COL.2:GOS.1000
60 MOVE Z,SC,3840:S=STICK(0):IF S=11:A=(A+1) MOD 12:ELSE:IF S=7:A=A-1:IF A<0:A=11:ENDIF:ENDIF:ENDIF:COLOR 2:GOSUB 1000

• MOVE Z,SC,3840 — copy the 'empty web' snapshot
• S=STICK(0) — grab the state of the joystick
• IF S=11 — if pushing left
  • A=(A+1) MOD 12 — move around the web one direction (0-11)
• ELSE
  • IF S=7 — if pushing right
    • A=A-1 — move around the web in the other direction (11-0)
    • IF A<0 — if we went beyond 0...
      • A=11 — ...wrap around
    • ENDIF
  • ENDIF
• ENDIF
• COLOR 2 — set drawing color to 2
• GOSUB 1000 — jump to blaster-drawing routine

70 F.I=0TO4:IF BA(I)=A:BA(I)=-1:Q=Q+(1-BR(I))*100:?Q:END.:IF BA(I)=-1:IF RAND(10)=0:BA(I)=RAND(12):BR(I)=0.03:END.:ELSE
70 FOR I=0 TO 4:IF BA(I)=A:BA(I)=-1:Q=Q+(1-BR(I))*100:? Q:ENDIF:IF BA(I)=-1:IF RAND(10)=0:BA(I)=RAND(12):BR(I)=0.03:ENDIF:ELSE

• FOR I=0 TO 4 — for each enemy (0-4)
  • IF BA(I)=A — if they're on the same segment of the web as the blaster...
    • BA(I)=-1 — disable the enemy
    • Q=Q+(1-BR(I))*100 — accumulate points based on how far up the web it has reached
    • ? Q — show your new score
  • ENDIF
  • IF BA(I)=-1 — if the enemy is not active...
    • IF RAND(10)=0 — there's a 1-in-10 chance that we'll...
      • BA(I)=RAND(12) — enable the enemy (on a random segment, 0-11)
      • BR(I)=0.03 — at the farthest distance
    • ENDIF
  • ELSE — (enemy was already active...)

80 BR(I)=BR(I)+0.1:IF BR(I)>1:BA(I)=-1:ELSE:COL.3:GOS.2000:END.:END.:N.I:L=L+1:IF L=200:END:END.:GOTO 60
80 BR(I)=BR(I)+0.1:IF BR(I)>1:BA(I)=-1:ELSE:COLOR 3:GOSUB 2000:ENDIF:ENDIF:NEXT I:L=L+1:IF L=200:END:ENDIF:GOTO 60

• BR(I)=BR(I)+0.1 — make the enemy move up the web
• IF BR(I)>1 — if they reach the top...
  • BA(I)=-1 — disable the enemy
• ELSE
  • COLOR 3 — set drawing color to 3
  • GOSUB 2000 — jump to enemy-drawing routine
• ENDIF
• ENDIF
• NEXT I
• L=L+1 — increase time counter
• IF L=200 — if we've reached the time limit...
  • END — end the program
• ENDIF
• GOTO 60 — otherwise, go back to the beginning of the main loop

Blaster-drawing routine

1000 A2=(A+1)MOD12:R1=R(A):R2=R(A2):PL.CX(A)*R1+CX,CY(A)*R1+CY:DR.CX,CY:DR.CX(A2)*R2+CX,CY(A2)*R2+CY:RET.
1000 A2=(A+1) MOD 12:R1=R(A):R2=R(A2):PLOT CX(A)*R1+CX,CY(A)*R1+CY:DRAWTO CX,CY:DRAWTO CX(A2)*R2+CX,CY(A2)*R2+CY:RETURN

• A2=(A+1) MOD 12 — get the next segment, relative to blaster (wrapping around 11-0)
• R1=R(A) — get radius at current segment
• R2=R(A2) — and radius at next segment
• PLOT CX(A)*R1+CX,CY(A)*R1+CY — plot a point at the first segment (near)
• DRAWTO CX,CY — draw a line to the center of the screen (far)
• DRAWTO CX(A2)*R2+CX,CY(A2)*R2+CY — draw a line back up to the second segment (near)
• RETURN

Enemy-drawing routine

2000 BR=BR(I):M=BA(I):R=R(M)*BR:A2=(M+1)MOD12:R2=R(A2)*BR:PL.CX(M)*R+CX,CY(M)*R+CY:DR.CX(A2)*R2+CX,CY(A2)*R2+CY:RET.
2000 BR=BR(I):M=BA(I):R=R(M)*BR:A2=(M+1) MOD 12:R2=R(A2)*BR:PLOT CX(M)*R+CX,CY(M)*R+CY:DRAWTO CX(A2)*R2+CX,CY(A2)*R2+CY:RETURN

• BR=BR(I) — get this enemy's distance down the web
• M=BA(I) — get this enemy's position (segment) around the web
• R=R(M)*BR — scale web segment's radius by the enemy's distance (0.03-1.00)
• A2=(M+1) MOD 12 — get the next segment, relative to enemy (wrapping 11-0)
• R2=R(A2)*BR — scale that web segment's radius
• PLOT CX(M)*R+CX,CY(M)*R+CY — plot a point at along segment 1
• DRAWTO CX(A2)*R2+CX,CY(A2)*R2+CY — draw a line across to segment 2
• RETURN
